Shuntian manufactures custom vacuum hot press machines for material lamination, compression forming, powder densification, high-temperature sintering and diffusion bonding.
Our product range covers servo-controlled vacuum hot presses for membranes, composite sheets and energy materials, as well as high-temperature vacuum hot press furnaces for ceramics, powder metallurgy, refractory metals and advanced aerospace materials.
By coordinating vacuum, temperature, pressure, displacement and holding time, the equipment helps reduce trapped air, oxidation, internal voids, uneven bonding and inconsistent material density.
Available configurations include laboratory vacuum hot presses, 30T to 500T servo vacuum presses, vacuum molding machines, multi-layer vacuum hot and cold pressing lines and high-temperature vacuum hot press furnaces.
Each Vacuum Hot Press Forming Machine system can be customized according to the material, component dimensions, required pressure, operating temperature, vacuum level, cycle time and production capacity.
Shuntian provides two main types of vacuum hot pressing equipment.
These machines use heated platens, a vacuum chamber and a servo-controlled pressing system. They are designed for relatively low- or medium-temperature processes such as lamination, curing, encapsulation, forming and bonding.
Typical equipment includes:
30T Servo Vacuum Hot Press Machine
100T Vacuum Molding Machine
500T Servo Vacuum Hot Press
Multi-Layer Vacuum Hot/Cold Pressing Automatic Line
Customized laboratory vacuum hot press
Automated vacuum thermal pressing line
Shuntian currently lists 30T, 100T and 500T vacuum pressing equipment for fuel cell, membrane, composite and related manufacturing applications.
A high-temperature vacuum hot press machine furnace combines a heated furnace chamber, vacuum system and uniaxial pressing mechanism.
It is mainly used for:
Powder densification
Ceramic hot pressing
Composite material sintering
Diffusion bonding
Refractory metal processing
Target material production
High-temperature material research
Shuntian’s existing high-temperature model is configured for temperatures up to 2400°C, long-term operation around 2200°C, vacuum levels down to 6.7 × 10⁻³ Pa and optional argon or nitrogen atmospheres. Final parameters depend on the selected heating and vacuum systems.
| Equipment Type | Main Process | Suitable Materials | Typical Applications |
|---|---|---|---|
| Servo Vacuum Hot Press | Vacuum lamination, bonding and compression forming | Membranes, films, composites, polymers and layered materials | MEA, CCM, sealing frames, functional films and composite sheets |
| Vacuum Molding Machine | Heating and vacuum-assisted molding | Polymer sheets, composite sheets and multilayer products | Energy materials, automotive films and molded composite parts |
| Multi-Layer Vacuum Hot Press | Simultaneous pressing of multiple layers or products | Films, membranes, laminates and sheet materials | Batch manufacturing and automatic production lines |
| Vacuum Hot and Cold Press | Heating, pressing and controlled cooling | Thermoplastic composites and dimension-sensitive laminates | Parts requiring reduced warping and stable final thickness |
| High-Temperature Vacuum Hot Press Furnace | Sintering and powder densification | Ceramics, cermets, refractory metals and powder materials | Ceramic tools, targets, structural ceramics and advanced materials |
| Vacuum Diffusion Bonding Press | Solid-state bonding under heat and pressure | Titanium, nickel alloys, stainless steel and dissimilar materials | Heat exchangers, aerospace structures and multilayer metal components |
A vacuum hot press applies heat and mechanical pressure to a material inside an evacuated chamber.
The vacuum removes air and reduces the presence of oxygen and other gases around the workpiece. The pressing system then applies controlled force while the material is heated.
Depending on the equipment configuration, this process can be used to:
Laminate multiple material layers
Remove trapped air and bubbles
Cure adhesive or resin systems
Form heated composite sheets
Control final product thickness
Densify ceramic or metal powders
Reduce pores inside a sintered component
Produce diffusion-bonded interfaces
Process oxidation-sensitive materials
A vacuum hot press is different from a standard open hot press because the material is processed inside a sealed or partially sealed vacuum environment.
It is also different from a vacuum furnace without pressing capability. A vacuum furnace only provides thermal processing, while a vacuum hot press simultaneously applies controlled heat and uniaxial mechanical pressure.
The exact process depends on whether the machine is used for lamination, molding, sintering or diffusion bonding.
A typical vacuum hot pressing cycle includes the following stages.
The material, component or powder-filled mold is positioned between the pressing platens or rams.
Depending on the application, the material may be loaded as:
Stacked films
Membrane assemblies
Prepreg sheets
Composite laminates
Polymer plates
Metal sheets
Ceramic powder
Metal powder
Graphite mold assemblies
Diffusion bonding components
The vacuum chamber, vacuum hood or mold enclosure is closed.
The sealing structure must match the required vacuum level, operating temperature, platen movement and loading method.
The vacuum system removes air and process gases from the chamber.
For membrane and composite pressing, the primary objective is often to reduce trapped air, bubbles and voids.
For high-temperature sintering or diffusion bonding, vacuum also helps limit oxidation and gaseous contamination during heating.
The system heats the platens, mold or furnace hot zone according to a programmed temperature curve.
Depending on the machine, heating may be provided by:
Electric heating platens
Cartridge heaters
Thermal oil circulation
Graphite resistance heating
Molybdenum heating elements
Tungsten heating elements
Induction heating
Industrial vacuum hot press furnaces commonly use graphite, molybdenum or tungsten hot zones according to the required temperature, atmosphere and contamination limits.
The servo-electric or servo-hydraulic system applies force to the material.
The press can be programmed for:
Constant force
Constant pressure
Constant position
Displacement control
Multi-stage pressure
Gradual loading
Pressure holding
Slow decompression
Pressure may be applied before heating, during heating or after the material reaches the required temperature.
Temperature, pressure and vacuum are maintained for the specified process time.
During lamination, this stage allows the adhesive, polymer or membrane layers to bond and flow.
During powder hot pressing, pressure assists particle rearrangement, deformation and densification.
During diffusion bonding, controlled temperature and pressure promote close interface contact and atomic diffusion without creating a conventional molten weld pool.
Some materials must remain under pressure during cooling.
Cooling under pressure can help:
Stabilize final thickness
Reduce warping
Prevent layer separation
Maintain dimensional accuracy
Improve surface flatness
Shorten the production cycle
Cooling can take place inside the same press or in a separate cold-pressing station.
After the product reaches the required unloading temperature, the chamber is returned to atmospheric pressure and the product is removed.
Process curves and batch data can be stored for production analysis and traceability.
Servo vacuum hot presses are suitable for pressing multilayer components that are sensitive to bubbles, uneven pressure and thickness variation.
Typical applications include:
Membrane electrode assemblies
Catalyst-coated membranes
Gas diffusion layers
MEA sealing frames
Fuel cell composite plates
Electrolyzer membrane assemblies
Ion-exchange membranes
Multilayer functional films
Shuntian’s 30T servo vacuum hot press is designed around a cycle that includes chamber sealing, evacuation, heating, servo-controlled pressing, holding and cooling.
Vacuum thermal pressing can be used for:
Carbon fiber composite panels
Glass fiber reinforced sheets
Thermoplastic composite parts
Honeycomb sandwich panels
Prepreg laminates
Lightweight structural panels
Automotive composite components
Aerospace composite structures
The vacuum environment helps reduce trapped air, while pressure consolidates the material layers and controls final thickness.
Typical materials include:
Polymer films
Functional membranes
Protective films
Adhesive layers
Insulation films
Flexible electronic materials
Battery separator materials
Multilayer barrier films
For thin films and membranes, platen parallelism, temperature uniformity and low-force control are often more important than maximum press tonnage.
Vacuum hot presses can be configured for:
Flow battery bipolar plates
Graphite composite plates
Electrode sheets
Battery insulation materials
Thermal interface materials
Aerogel insulation sheets
Energy storage sealing components
Multilayer battery materials
High-temperature vacuum hot press furnaces are commonly used to densify advanced ceramics and ceramic composites.
Applicable materials may include:
Silicon carbide
Silicon nitride
Boron carbide
Aluminum nitride
Alumina
Zirconia
Borides
Nitrides
Carbides
Ceramic matrix composites
Vacuum or inert-gas processing is particularly important for non-oxide ceramics that may react with oxygen during high-temperature treatment.
Vacuum hot pressing can be used to manufacture dense components from:
Metal powders
Alloy powders
Intermetallic compounds
Refractory metal powders
Cermets
Composite powders
Functional target materials
Additive manufacturing feedstock or preforms
Pressure-assisted sintering can achieve densification at a different temperature-time combination from pressureless sintering, although the final process must be validated for each powder system.
Vacuum hot presses can join prepared material surfaces using controlled heat and pressure.
Typical diffusion bonding products include:
Printed circuit heat exchangers
Microchannel heat exchangers
Heat sinks
Titanium multilayer structures
Aerospace hollow panels
Stainless steel laminates
Nickel-alloy assemblies
Metal-to-ceramic structures
Hot presses are widely used for both powder sintering and diffusion bonding of metals, ceramics and composite materials.
Applications include:
Titanium alloy structures
Nickel-based superalloy components
Thermal protection materials
Refractory metal parts
Carbon-carbon composites
Ceramic aerospace components
Rocket and satellite materials
High-temperature material research
